Aluminum 6101 for Busbar Conductor and Supercharging Piles POSITION:  Home > Product > 6xxx alloy

Aluminum 6101 for Busbar Conductor and Supercharging Piles

What Is Aluminum 6101

6101 aluminum sheet.jpg6101 aluminum is a kind of American deformed aluminum. It has good corrosion resistance and weldability, which is used for processing high-strength bus conductors. 6101 aluminium plate is often used in high-strength aluminum materials for buses, electric conductors and radiator materials, bus conductors, etc.

Properties of 6101 Auto Aluminum

Machinability by conventional means is good. Its forming ability is also good. It is applicable for all the standard processes including gas torch welding. However, the best welding method is inert gas arc welding. The filler rod of the same alloy should be used. It can be strengthened by heat treatment.

Specification of Aluminum 6101 for Bus Bar

Chemical Composition

Alloy

Si

Fe

Cu

Mn

Mg

Cr

Zn

B

Standard(wt%)

6101

0.30-0.70

0.50

0.1

0.03

0.35-0.80

0.03

0.1

0.06

EN

573-3-2007

Mechanical Properties

Alloy

Temper

Yield Strength

Rp0.2(Mpa)

Tensile Strength

Rm(Mpa)

Conductivity

%IACS

Bending

6101

T63

150

185

56

90°1t

T64

55

105

59.5

90°1t

Size

Alloy

Temper

Thickness(mm)

Width(mm)

Length(mm)

6101

T63/T64

2-8

1200-2650

2000

What is 6101 Bus Bar

An electrical bus bar refers to a conductor or a group of conductor used for collecting electric power from the incoming feeders and distributes them to the outgoing feeders. It has many shapes including rectangular, cross-sectional and round shape.

The rectangular bus bar is mostly used in the power system. The copper and aluminium are used for the manufacturing of the electrical bus bar. In terms of lightweight, aluminum 6101 has bigger advantage.

6101 bus bar.jpg

6101 VS Other Aluminum Alloys

  • 6101 aluminum is similar to 6063 aluminum alloy, but it has minor chemistry changes when its electrical conductivity is enhanced.

  • Alghough its conductivity is a little lower than thaof 1350 alloy, 6101 alumnum has greater strength.

FAQ:

1. What Is Your MOQ?

The MOQ of each specification is 8 tons. If your order is less than 8 tons, welcome to contact us directly. We will help you to check the aluminum sheets in stock.

2. Are you a aluminum sheet manufacturer or a distributor?

Haomei Aluminum is a large-scale aluminum sheet manufacturer. Our automotive aluminum sheets have been exported to over 80 countries.

3. Is your 6101 aluminum sheet price fixed?

The 6101 aluminium sheet price consists of aluminum ingot price and processing fees. As the price of aluminum ingots fluctuates daily, the quotation will fluctuate.

4. How to get a quotation?

Please tell us thickness, width, length (mm), total demand (tons), so that we can provide you with an accurate quotation. Such as: 6101 aluminum plate, 3*1200*2000mm, demand 15 tons/month, for bus bar of electric vehicles.


Original Source:https://www.autoaluminumsheet.com/product/aluminum-6101-for-busbar-conductor-and-supercharging-piles.html

Tags: aluminum 6101 ,  6101 aluminum bus bar ,  auto aluminum ,
